• Long-life Electronics
• Dali-2 Compliant And Certified
• Protected Against Dali Over-voltage
• Compatible With Dali Devices And Systems
• Suitable For One Dali Line Of Up To 64 Devices
• Suitable For Distribution Board Mounting On Standard Din Rail

• Compliant To Iec 62386-103 Ed 2.0, Multi Master Application Controller
• Led Indicators For System Status
• Reinforced Insulation Between Dali, Mains Supply And Ethernet
• 10/100 Tcp/ip Ethernet Compatible W. Standard It Switches And Equipment
• Emergency Testing And Reporting Using Iec 62386-202

• 235 Ma Dali Line Current
• Protected Against Short Circuit
• Tested And Compliant To Iec 62386-101 Ed 2.0
• Advanced Bus Power Supply, As Defined By Iec 62386-101 Ed 2.0

• Dali (Iec62386)

Controller Specifications

• Supply Voltage: 220-240 ~ 50hz
• Control System: Dali-2
• Ethernet: 10 / 100 Tcp / Ip Ethernet
• Ambient Temperature: 0 – 45°c
• Class: 2
• Wiring: 1 – 4 Mm2
• Strip: 6 – 7 Mm
• IP Rating: IP20
• Mounting Type: Din Rail (35 Mm)
• Body: Pc V2, 750 Glow Wire

Power Supply Specifications

• Supply Voltage: 220-240v ~ 50hz
• Control System: Dali-2
• Guaranteed Supply Current: 235 Ma
• Maximum Supply Current: 250 Ma
• Dali Voltage: 16.5 V Nominal Line Voltage
• Ambient Temperature: 0 – 45°c
• Class: 2
• Wiring: 1 – 4 Mm2
• Strip: 6 – 7 Mm
• IP Rating: IP20
• Mounting Type: Din Rail (35 Mm)
• Body: Pc V2, 750 Glow Wire
